PCA：把資料壓縮時保留了什麼？

樣本共變異數 C = Xcᵀ Xc / (n−1)
方向u上的樣本變異 = uᵀ C u，限制 ||u||=1

Xc = U Σ Vᵀ
取前k個方向Vk：Z = Xc Vk
重建：X̂ = Z Vkᵀ + μ

C = [[10/3, 2],
     [2, 10/3]]

第一方向 u1 = (1,1)/√2，變異 λ1=16/3
第二方向 u2 = (1,−1)/√2，變異 λ2=4/3
第一PC解釋比例 = (16/3)/(20/3) = 0.8

python -m pip install numpy==1.26.3 scikit-learn==1.5.1
python pca_projection.py

import numpy as np
import sklearn
from sklearn.decomposition import PCA
from sklearn.datasets import load_digits
from sklearn.model_selection import train_test_split
from threadpoolctl import threadpool_limits

X = np.array([[12.0, 22.0], [8.0, 18.0],
              [11.0, 19.0], [9.0, 21.0]])
centered = X - X.mean(axis=0)
covariance = centered.T @ centered / (len(X) - 1)
u = np.array([1.0, 1.0]) / np.sqrt(2.0)
scores = centered @ u
reconstructed = scores[:, None] * u + X.mean(axis=0)
with threadpool_limits(limits=1):
    full = PCA(n_components=2, svd_solver="full").fit(X)
    one = PCA(n_components=1, svd_solver="full").fit(X)
    one_reconstructed = one.inverse_transform(one.transform(X))
    print(f"numpy={np.__version__} sklearn={sklearn.__version__}")
    print(f"toy mean={X.mean(axis=0).tolist()}")
    print("toy covariance=" + np.array2string(covariance, precision=6))
    print("toy explained_variance=" +
          ",".join(f"{v:.6f}" for v in full.explained_variance_))
    print("toy explained_ratio=" +
          ",".join(f"{v:.6f}" for v in full.explained_variance_ratio_))
    print("toy scores_on_positive_diagonal=" +
          ",".join(f"{v:.6f}" for v in scores))
    print(f"toy reconstructed={reconstructed.round(6).tolist()}")
    print(f"toy rank1_SSE={np.square(X - one_reconstructed).sum():.6f}")
    print(f"toy entrywise_MSE={np.square(X - one_reconstructed).mean():.6f}")
    print(f"toy direct_and_sklearn_reconstruction_match="
          f"{np.allclose(reconstructed, one_reconstructed)}")

    # All pixel features share the same original intensity units.
    # Labels are used only for a stratified split, never for fitting PCA.
    digits, labels = load_digits(return_X_y=True)
    train, test = train_test_split(
        np.arange(len(digits)), test_size=0.25,
        stratify=labels, random_state=42,
    )
    model = PCA(n_components=0.95, svd_solver="full").fit(digits[train])
    train_back = model.inverse_transform(model.transform(digits[train]))
    test_back = model.inverse_transform(model.transform(digits[test]))
    print(f"digits train={len(train)} test={len(test)} original_features=64 "
          f"retained_components={model.n_components_}")
    print(f"digits train_explained_ratio_sum="
          f"{model.explained_variance_ratio_.sum():.6f}")
    print(f"digits train_pixel_MSE={np.square(digits[train] - train_back).mean():.6f}")
    print(f"digits test_pixel_MSE={np.square(digits[test] - test_back).mean():.6f}")
    print(f"digits mean_fit_on_train_only="
          f"{np.allclose(model.mean_, digits[train].mean(axis=0))}")
